BJ-III disintegrator

NegotiableUpdate on 01/15

Model

Nature of the Manufacturer: Producers

Product Category

Place of Origin

Online Consult

Overview

The BJ-III disintegrator adopts a 3-cup design and can conduct 3 sets of disintegration time limit tests simultaneously. The overall water bath design ensures a more stable and uniform water bath temperature. Using high-precision platinum resistance Pt1000 sensor, the temperature is more accurate. Quick disassembly of the hanging basket allows for quick disassembly and assembly of the hanging basket.

Product Details

BJ-III disintegrator

The disintegrator adopts a 3-cup design and can conduct 3 sets of disintegration time limit tests simultaneously. The overall water bath design ensures a more stable and uniform water bath temperature. Using high-precision platinum resistance Pt1000 sensor, the temperature is more accurate. Quick disassembly of the hanging basket allows for quick disassembly and assembly of the hanging basket.

Technical Specifications:

1. Temperature pre fabrication range: room temperature~45 ℃

2. Temperature control accuracy: ± 0.3 ℃

3. Timed prefabrication range: 1min~999min

4. Time control accuracy: ± 0.5min

5. Noise: ≤ 60dB

6. Number of lifting baskets: 3 sets, can operate independently

7. Basket lifting frequency: (30-32) times/minute

8. Basket lifting distance: (55 ± 1) mm

9. Minimum distance from sieve to cup bottom: 25mm ± 2mm

10. Mesh aperture: 2mm

11. The water bath temperature is 37.0 ℃ and can be reset to the preset temperature in both directions at any time.

12. The digital display shows temperature and time.

13. It has the functions of water bath temperature overheating alarm and automatic protection.
