Chengli Special Purpose Vehicle Co., Ltd
Dongfeng Dorica oil tanker truck
NegotiableUpdate on 03/18
- Model
- Nature of the Manufacturer
- Producers
- Product Category
- Place of Origin
Overview
Vehicle Description:
Product Details
| Main technical parameters of Chengliwei brand CLW5120GJYE5 Dongfeng Dorica oil tanker truck | |||
| Product Name: | Dongfeng Dorica oil tanker truck | External dimensions: | 6950×2200×2800(mm) |
| Chassis model: | EQ1127SJ8GDC | Cargo compartment size: | ××(mm) |
| Total mass: | 12495(Kg) | Approach/departure angle: | 20/11(°) |
| Rated quality: | 6800(Kg) | Front suspension and rear suspension: | 1130/1465,1130/1630,1130/1810(mm) |
| Curb weight: | 5500(Kg) | Maximum speed: | 80(km/h) |
| engine | Engine Manufacturer | Displacement (ml) | Power (kw) |
| YC4S150-50 YC4FA130-50 CY4BK151 |
Guangxi Yuchai Machinery Co., Ltd Guangxi Yuchai Machinery Co., Ltd Dongfeng Chaoyang Chaochai Power Co., Ltd |
3767 2982 3856 |
110 95 105 |
| Emission standards: | GB17691-2005 National V, GB3847-2005 | ||
| Number of axes: | 2 | Front wheelbase: | 1740(mm) |
| wheelbase: | 3300,3650,3800 | Rear wheelbase: | 1640(mm) |
| Number of tires: | 6 | Tire specifications: | 8.25R20 14PR,8.25-20 16PR |
| Fuel type: | diesel oil | Number of spring plates: | 8/10+7 |
| Axle load: | 4995/7500 | Number of passengers in the cab: | 3 |
| Vehicle remarks: | 1. The effective volume of the tank is 8.6 cubic meters, and the external dimensions of the tank (length x long axis x short axis) (mm) are 4700 x 2000 x 1330. Class number: 3. 2. Protective material: Q235A carbon steel, connection method: welding connection is used for the left and right sides and the lower rear protection. The cross-sectional size of the rear protection (mm) is 100 × 50, and the height of the rear protection above the ground (mm) is 370. 3. This vehicle can be equipped with: Henghe Jiahua brand, Bolai brand, Zhengxing brand, Hengshan brand, Huate brand, Zhengruntong brand tax controlled fuel dispensers, corresponding models are: SKES-1112, SKDS-2001A, SC20D1110F, HS1812B, HT-YV60E, XTST121BF1. The corresponding manufacturers are: Henghe Jiahua Technology Co., Ltd., Shanghai Bolai Machinery Co., Ltd., Zhengxing Technology Co., Ltd., Token Hengshan Technology (Guangzhou) Co., Ltd., Suizhou Huate Special Equipment Co., Ltd., and Xingtai Zhengruntong Technology Development Co., Ltd. 4. Only radial tires and a chassis with ABS are used. The front wheels of the vehicle are equipped with disc brakes, front exhaust pipes, and speed limiting devices, with a speed limit of 80km/h. Install a driving recorder with satellite positioning function. ABS system manufacturer, model: Xiangyang Dongfeng Longcheng Machinery Co., Ltd, ABS/ASR-24V-4S/4M.5、 Vehicle colors are optional, and the position of text spraying can be changed; Optional upper walkway and toolbox location; Optional cab with chassis. Types of dangerous goods transport vehicles (FL type vehicles) | ||
| Multi directional diagram: |
   |
||
| For more information and product pictures, please contact our company directly. We will provide you with the best service! | |||
