Low temperature circulating vacuum pump
NegotiableUpdate on 02/11
- Model
- Nature of the Manufacturer
- Producers
- Product Category
- Place of Origin
Overview
Low temperature circulating vacuum pump is a product developed based on the design of coolant circulating pump and circulating water vacuum pump. It has the functions of both a coolant circulation pump and a vacuum pump, and can be used in conjunction with a rotary evaporator to improve distillation efficiency and solvent recovery rate.
Product Details
Low temperature circulating vacuum pumpyesA product developed based on the design of coolant circulation pumps and circulating water vacuum pumps. It has the functions of both a coolant circulation pump and a vacuum pump, and can be used in conjunction with a rotary evaporator to improve distillation efficiency and solvent recovery rate.
Low temperature circulating vacuum pumpProduct Features
Integrating negative pressure acquisition and cooling, combining the characteristics of coolant circulation pump and vacuum pump, it can simultaneously vacuum and cool the rotary evaporator;
The self cooling cycle system can control the water temperature within4Around ℃, keep the vacuum pump atZGood working condition to ensure negative pressure indicators;
Equipped with three taps, it can provide negative pressure conditions for three loads simultaneously. There are three vacuum gauges available to directly monitor negative pressure indicators;
The evaporator material is stainless steel(06Cr19Ni10).
Main technical parameters
model |
DLSB-ZC |
|
Temperature range for use(℃)［1］ |
-10～25 |
|
ambient temperature(℃) |
5～25 |
|
temperature stability(℃) |
±2 |
|
Total machine power(W) |
1650 |
|
power supply |
220-240V～,50HZ |
|
Storage tank capacity(L) |
20 |
|
refrigeration capacity(W) |
600~2550 |
|
circulation pump |
power(W) |
280 |
rated flow(L/min) |
30 |
|
Pressure（bar） |
1.0 |
|
Z大真空度（MPa）/Ultimate pressure（mbar） |
0.098/20 |
|
Number of exhaust heads (pcs) |
3 |
|
Single head pumping rate（L/min） |
10 |
|
Overall dimensions(mm) |
595W×475D×925H |
|
