Tilt type small vacuum packaging machine

NegotiableUpdate on 03/10

Model

Nature of the Manufacturer: Producers

Product Category

Place of Origin

Online Consult

Overview

Tilt type small vacuum packaging machine

Product Details

Product Name:DZ (Q) -500/2SC tilting small vacuum packaging machine

Product Code:DZ(Q)-500/2SC

detailed description:

1、 Product Introduction
DZ series vacuum (inflatable) packaging machine, simply press the vacuum chamber cover to complete the vacuuming process according to the set program, then fill with inert gas, seal, and print,
The entire process of cooling and exhaust. Vacuum packed items can prevent oxidation, mold, insect damage, moisture, and extend product storage lifeAfter tilting the workbench, it can be applied to vacuum packaging containing liquids. This product's studio and rack are both made of stainless steel material, and the workbench can be tilted freely0-45 °.

2、 Technical parameters

model	DZ(Q)-500/2SC	DZ(Q)-600/2SC
voltage	2200380V/50-60HZ	2200380V/50-60HZ
Vacuum pump power	1.5KW	2.5KW
Heat sealing power	1.17KW	1.17KW
Minimum absolute pressure	0.1Kpa	0.1Kpa
Chamber Size	520520160mm	620620160mm
Size of heat seal strip	500×10mm	600×10mm
Number of heat seals	4pcs	4pcs
Vacuum pump displacement	40m3/h	63m3/h
Vacuum chamber material	Stainless steel	Stainless steel
Machine size (L × W × H):	1260610950mm	1460710950mm
weight	150kgs	180kgs
