Ultrasonic explosion-proof generator screening system Artech ultrasonic frequency conversion system, one generator can activate multiple screens at the same time, so Artech system can provide screening machines with diameters up to 3 meters and can be evenly and effectively distributed on the screen. The system consists of the following components: pre tensioned screen, ultrasonic generator, ultrasonic transducer, waveguide rod, screen, waveguide, HF cable connection, and support structure. It can effectively screen powders smaller than 500um, increase production, disperse agglomerates, and reduce large particles

Product Details

Artech brand DGS35 ultrasonic explosion-proof generator for separation equipment

Artech Ultrasonic Systems, a subsidiary of Crest Holdings, is a Swiss company specializing in ultrasonic technology. The developed and technologically advanced variable frequency ultrasonic screening technology can also be applied in other fields, such as ultrasonic quantitative feeding, ultrasonic feeding, cleaning dry powder, and ultrasonic cutting.

Artech - Screening System

The Artech ultrasonic frequency conversion system can activate multiple screens simultaneously with one generator, so the Artech system can provide screening machines with diameters up to 3 meters and evenly and effectively distribute them on the screen.

The Artech screening system consists of the following components:

Pre tensioned sieve mesh

The ultrasonic generator

Super device transducer

Waveguide rod

Sieve waveguide

HF cable

Connection and its bracket structure

Can screen powders smaller than 500um more effectively

increase production

Dispersed aggregates

Reduce the number of large particles

Ensure that the screen mesh is clean

Reduce adhesion between materials and container walls during quantitative feeding or conveying processes.

Advance (Gaoben) collaborates with the Artech ultrasonic system for comparison, using a new screening machine ultrasonic system to manufacture a screening machine with more outstanding micro powder separation performance!

As the general agent in Chinese Mainland, we will provide more timely transformation and maintenance services for advanced users of high-performance ultrasonic screening machines, as well as the overall design of ultrasonic high-energy screening machines, and change the two-layer and three-layer use of two or three sets of power generators into a more sophisticated system, which is a relatively good technology!

In the field of screening machines, especially ultrasonic screening machines, Gaoben is an excellent supplier.

Advance makes particle separation easier.

We have more experience in ultrafine powder classification. Whether it's the production screening and grading of dry particle micro powder, sample inspection, or the filtration of ultrafine slurry and wet particle grading, Advance can provide new technology products!

In the specific field of high-energy ultrasonic screening, Advance has achieved a relatively advanced position.

PS: Under standard conditions, each ultrasonic screening system includes one ultrasonic generator, one transducer, one data cable, and one conversion screw.

The variability of frequency requires a robust ultrasonic generator that can handle the powerful current and voltage generated when the frequency changes,. Artech produces this type of electrical box.

All electrical boxes comply with Atex Zone 22 explosion-proof standards

Separation equipmentArtech brand DGS35 ultrasonic explosion-proof generatorparameter

Generator type	: Single (1 high-frequency cable) Twin (2 high-frequency cables)
Ultrasonic power	： 50/100/ 200 Watt
output voltage	： 600V（limited）
output current	： 0.5 A (limited)
Output frequency (frequency variation)	30-38 kHz (frequency variation)
Operation Mode	: Automatic mode : Manual mode
Protection type	： IP65
voltage level	： II
standard weight	： 3.6 kg
size	： 280 x 170 x 125 mm
Electrical connector	： 110-220V
frequency	： 50/60 Hz
ambient temperature	： 0–45 °C
Relatively high humidity	： 80 % at 30° C
Installation level	： II
operating area	： indoors, 2000m above sea level
