ZBJ-1100S Continuous Vacuum Packaging Machine (Double Seal)
NegotiableUpdate on 04/27
- Model
- Nature of the Manufacturer
- Producers
- Product Category
- Place of Origin
Overview
ZBJ-1100S continuous vacuum packaging machine is designed with double sealing lines, mainly for small bag packaging, and is often suitable for packaging Zongzi, leisure food, etc. The maximum sealing line of the vacuum packaging machine can reach 1100mm, which can meet the requirements of high production. The ZBJ-1100S continuous vacuum packaging machine has the advantages of smooth lifting, high accuracy, and accurate positioning of the rolling belt; Equipment operators do not need to manually adjust the position of the conveyor belt, which saves time and effort. The hardware configuration of ZBJ-1100S continuous vacuum packaging machine is relatively high. The contactor adopts Omron from Japan, and the switchgear adopts Schneider brand from France, with reliable quality and stable performance. ZBJ-1100S continuous vacuum packaging machine, with fully sealed operating system, can be washed with clean water, and is widely used in the production of Pickled vegetables or packaging of items with liquid. Continuous vacuum packaging machine is a commonly used high output food vacuum packaging machine. Scope of application: especially suitable for small packages of Pickled vegetables, vegetables, frozen products, aquatic products, dried tofu, leisure food, etc
Product Details
Performance characteristics:
ZBJ-1100S Continuous Vacuum Packaging MachineIt is a double sealing line design, mainly for small bag packaging, which is often applicable to the packaging of Zongzi, leisure food, etc. The maximum sealing line of the vacuum packaging machine can reach 1100mm, which can meet the requirements of high production. The ZBJ-1100S continuous vacuum packaging machine has the advantages of smooth lifting, high accuracy, and accurate positioning of the rolling belt; Equipment operators do not need to manually adjust the position of the conveyor belt, which saves time and effort.
The hardware configuration of ZBJ-1100S continuous vacuum packaging machine is relatively high. The contactor adopts Omron from Japan, and the switchgear adopts Schneider brand from France, with reliable quality and stable performance.
ZBJ-1100S continuous vacuum packaging machine, with fully sealed operating system, can be washed with clean water, and is widely used in the production of Pickled vegetables or packaging of items with liquid. Continuous vacuum packaging machine is a commonly used high output food vacuum packaging machine.
Scope of application: especially suitable for small packages of Pickled vegetables, vegetables, frozen products, aquatic products, dried tofu, leisure food, etc
Advantage：
·Anti pinch device
·Variable frequency speed regulation, slow start, slow stop conveyor device, more accurate positioning
·Improved transformer and electric heating rod, easy replacement of electric heating belt, longer service life
·Equipped with a specially designed German M-type 6mm double peak sealing wire and a special pressure sealing device, the thick material and folds can be sealed without air leakage
·Wire cutting completed, stainless steel formed
·Original imported electrical components
optional function：
·Optional belt frequency converter
·Optional spacing for sealing strips
·Mechanical version, computer board optional
·Vacuum pump optional
·The width of the sealing strip is optional
ZBJ-1100S Continuous Vacuum Packaging MachineIt is a double sealing line design, mainly for small bag packaging, which is often applicable to the packaging of Zongzi, leisure food, etc. The maximum sealing line of the vacuum packaging machine can reach 1100mm, which can meet the requirements of high production. The ZBJ-1100S continuous vacuum packaging machine has the advantages of smooth lifting, high accuracy, and accurate positioning of the rolling belt; Equipment operators do not need to manually adjust the position of the conveyor belt, which saves time and effort.
The hardware configuration of ZBJ-1100S continuous vacuum packaging machine is relatively high. The contactor adopts Omron from Japan, and the switchgear adopts Schneider brand from France, with reliable quality and stable performance.
ZBJ-1100S continuous vacuum packaging machine, with fully sealed operating system, can be washed with clean water, and is widely used in the production of Pickled vegetables or packaging of items with liquid. Continuous vacuum packaging machine is a commonly used high output food vacuum packaging machine.
Scope of application: especially suitable for small packages of Pickled vegetables, vegetables, frozen products, aquatic products, dried tofu, leisure food, etc
Advantage：
·Anti pinch device
·Variable frequency speed regulation, slow start, slow stop conveyor device, more accurate positioning
·Improved transformer and electric heating rod, easy replacement of electric heating belt, longer service life
·Equipped with a specially designed German M-type 6mm double peak sealing wire and a special pressure sealing device, the thick material and folds can be sealed without air leakage
·Wire cutting completed, stainless steel formed
·Original imported electrical components
optional function：
·Optional belt frequency converter
·Optional spacing for sealing strips
·Mechanical version, computer board optional
·Vacuum pump optional
·The width of the sealing strip is optional
Technical parameters:
| Product Name/Specification | ZBJ-1100S Continuous Vacuum Packaging Machine (Double Seal) |
| Chamber Size | 1240mm in length, 540mm in width, and 115mm in height |
| seal dimensions | 1100mm |
| sealing width | 8-10mm |
| Effective sealing size | 180-280mm (longitudinal effective length) can be increased |
| Effective height | 100mm |
| Packaging capability | 4-6 times/minute |
| Machine size | Length 1800 x Width 1400 x Height 1500mm |
| Power Supply | 380/ 50HZ |
| Power | 5.5KW |
| machine weight | 700kg |
Comparison between Qingdao Mag's second-generation and third-generation machines
1. Comparison of pressure strips:
The diameter of the third generation press bar is 7 millimeters, and the diameter of the second generation press bar is 6 millimeters
2. Comparison of cover plates on side boxes:
The upper cover and chain cover of the third-generation machine side box are separate, which is very convenient for maintaining the chain. The upper cover and chain cover of the second-generation machine side box are integrated, which is quite inconvenient for maintaining the chain
3. Comparison of Studio Surface
The wiring screws and water nozzle of the third-generation machine are located at the back, and the surface of the studio is beautiful and easy to clean and maintain hygiene; The wiring screws and water nozzles of the second-generation machine are all on the surface of the studio, making cleaning and hygiene inconvenient and unsightly
4. Chain comparison:
The third-generation machine uses a large pitch chain with a pitch of 15.875 * 2, which has excellent tensile strength; The second-generation machine uses a pitch of 12.7, which has poor tensile strength of the chain and is prone to damage
5. Comparison of operation panels:
Third generation computer touch screen, brLC control, good waterproof effect, high intelligence. Or mechanical panels; The second-generation machine adopts a computer board controller and a button type switch, which is prone to damage
6. Comparison of discharge plates:
The third-generation machine has high strength, easy angle adjustment, and easy fixation; The second-generation machine has low strength and is prone to deformation during use. The angle is very difficult to adjust and cannot be fixed
7. Comparison of electrical boxes:
The third-generation machine has an independent electrical box, which is easy to maintain and not easily affected by moisture. The second-generation machine is located in a side box, which is inconvenient to maintain and prone to moisture
8. Bracket comparison:
Third generation machine made of 16mm 304 stainless steel plate; Production of 10mm stainless steel plate for second-generation machines
9. Comparison of belt hinges:
The third generation machine has its own mold made of 2mm 304 stainless steel, while the small hinges on the second generation machine market are prone to damage
10. Comparison of towing angle iron：
The third generation press plate uses a bent hook, which can be well fixed on a small belt without falling off, and has a large positioning distance; The second-generation press plate is flat and prone to detachment during use, with loose fixation,
11. Comparison of travel switch paddles:
Third generation CNC wire cutting machining with extremely high precision; The second-generation machine is handmade and lacks precision
12. Comparison of faucet and wiring:
The wiring screws and water nozzle of the third-generation machine are located at the back, and the surface of the studio is beautiful and easy to clean and maintain hygiene; The wiring screws and water nozzles of the second-generation machine are all on the surface of the studio, making cleaning and hygiene inconvenient and unsightly
13. Comparison of vacuum gauges:
Third generation imported 304 shell shockproof vacuum gauge; The ordinary iron shell watch of the second-generation machine is prone to rust and damage
14. Studio comparison:
Third generation machine made of 8mm stainless steel plate; Production of 5mm stainless steel plate for second-generation machines
