Elesa+Ganter Index piece spring plunger bracket/lateral stop

Spring plunger bracket is used for stopping and pressing or lowering components. The use of one or two countersunk screws for easy attachment also allows for its use, where positioning boreholes with tolerance range H7 for spring plungers cannot be determined by their size and manufacturability.

GN 614.1 Spring Piston Bracket Specification

type

-LKU type: fixed from the left side, with spring pin;

-RKU type: fixed from the right side, with spring pin;

-BKU type: can be fixed with spring pins from both sides;

-L-shaped: fixed from the left side, without a spring pin;

-R-type: fixed from the right side, without spring pins;

-Type B: Can be fixed from both sides, without springs or other pins;

Die cast zinc

nickel plating

Spring pin GN614-KU (see page 847)

shell

Plastic (polyoxymethylene POM)

Temperature tolerance up to 50C

AISI1420C stainless steel ball, hardened treatment

information

Spring plunger bracket/side push GN6141 is used for stopping and pressing or lowering components. The use of one or two countersunk screws for easy attachment also allows for its use, where positioning boreholes with tolerance range H7 for spring plungers cannot be determined by their size and manufacturability. GN614.1 Side Stop Promotion includes a spring pin bracket and a stainless steel spring pin. The GN614KU model (see page 847) only provides an "empty" bracket (without spring pins) for the R, L, and B models to be used with the GN614-6 and GN614-8 derivative styles of KDMS and NI models.
