Product Name:High speed reciprocating rotating friction and wear testing machine

Introduction to Basic Parameters:

This testing machine is used for testing the friction and wear performance of materials, material surface coatings, and component surfaces. Can provide a wide range of loads and rotational speeds. Different friction pairs of ball disc and pin disc can be tested, and the computer can automatically detect all measured parameters, friction coefficient, friction force, load, and torque under different friction modes during the test, and display them synchronously in the form of data and graphics. The installation environment control system can adjust the test temperature and ambient atmosphere for testing.

This instrument can be widely used in the research of material surface processing technology, evaluation of material failure and reliability, industrial product quality inspection and control. This device is equipped with automatic shutdown protection, easy operation, and high measurement accuracy.

Technical Specifications

Test load range 10-2000g (weight)Loading) Accuracy:1% F.S

Adjustable test speed 5-2000rpm (stepless speed regulation)

Test reciprocating frequency0-20Hz (accessories can be used for reciprocating friction test)

reciprocating stroke1-25mm

Adjustable X-axis movement distance 3～25mm

Z-axis lifting height adjustable 0～100mm

Adjustable friction diameter Φ3～Φ50mm

Lower sample size range 10～60mm、 Thickness range: 2-20mm

Size range of upper sample Ball or pin with a diameter of 3 to 6mmlength10-15mm (can be processed according to user requirements)

Friction measurement range ≦20N

Measurement accuracy of friction coefficient 0.2％F. S

heating moduletemperature room temperature~220℃optional

Friction measurement range: 0~20N

Friction system measurement accuracy: 0.2% FS (full range)

Friction environment (liquid): Environment box (stainless steel or PTFE) optional

Dimensions mm: 900 * 500 * 700

Weight: 60kg
