LNG analyzer, LNG nitrogen detector

Product Details

Liquefied natural gas (LNG) is a form of energy in which natural gas is compressed and cooled to its boiling point temperature to become a liquid. Its main component is methane, which is transported by specialized ships or tank trucks and re gasified during use. At present, LNG is mainly used in industry and vehicles in China.
Products cannot just be cheap, quality is very important! The consequences of being cheap can be fatal!

Mixing liquid nitrogen with LNG is not a new phenomenon in the industry and has been encountered in the liquid market. Add liquid nitrogen to LNG. It is reported that liquid nitrogen was originally only used to adjust the fixed calorific value of LNG, but due to its considerable profits, it has gradually become a profit-making method for some illegal merchants.

At present, the market price of liquid nitrogen is 1000 yuan/ton, while the price of LNG is currently 4500 yuan/ton, with a price difference of 3500 yuan/ton per ton. For the 22 ton transport vehicle with a high usage rate of liquefied natural gas, the general blending ratio is 10%, and the price difference of LNG per vehicle can reach 3500 yuan. If the released 2 tons of LNG are resold, the profit will be 7000 yuan, which means the profit per vehicle will reach nearly 10000 yuan, and the profit will be even more considerable in winter.

Shanghai Gas Spectrum Analysis Instrument Co., Ltd. quickly organized technical personnel to analyze natural gas samples based on user feedback. Through the unremitting efforts of technical personnel, a set of nitrogen detection methods and related instrument configurations for natural gas have finally been developed

LNG analyzer :

Product Name, Model, Specification, and Description

Gas chromatograph GC2020ATCD, eight way valve injection system+blowback

Chromatography workstation N2000 dual channel (computer, printer self equipped)

Column for Nitrogen Analysis in Natural Gas (Imported)

High purity hydrogen generator HK-300, hydrogen flow rate 300ml/min

Note: Dimensions: 350mm (length) * 150mm (width) * 300mm (height)

Whole machine weight: 10kg Input power supply: AC220V ± 10% 50HZ2KW

LNG nitrogen blending detector :

(1) Instrument installation

Place the instrument on a stable workbench, connect the workstation computer (equipped with a 9-pin serial port connector) to the instrument, install the workstation software, and place the online and offline workstation icons on the desktop. If hydrogen gas is used in a steel cylinder, it should be placed in a well ventilated space. Connect the gas pipeline and test for leaks with soapy water

(2) Before starting up the instrument, first open the hydrogen gas cylinder and output the pressure (0.3MPa). Check if the pressure gauge of the gas chromatograph instrument has risen to a pressure of (0.15MPa, subject to instrument debugging). After the pressure stabilizes, turn on the power switch of the gas chromatograph.

LNG nitrogen blending calorific value analyzer【precautions】：

1. The hydrogen generator must be turned on first when starting up!

2. Before use, the gas in the pipeline should be purged for 10-30 minutes to prevent oxidation of the rhenium tungsten wire.

3. Gas cannot be directly blown onto the thermal conductivity detector, or there may be significant gas flow impact.

4. Strong body vibrations are not allowed.

5. TCD should not be placed at the vent port, and should be connected to the outside through a pipeline.

6. When turning off the instrument, you can directly turn off the power switch and wait for 5 minutes before turning off the hydrogen generator
