YBB00162002 Aluminum Tube Coating Flexibility and Adhesion Tester

YBB00162002 Aluminum Tube Coating Flexibility and Adhesion Tester

In the field of modern pharmaceutical packaging, aluminum medicinal ointment tubes are widely favored due to their lightweight, durable, and easy to carry characteristics. However, for such packaging materials, the flexibility and adhesion of the coating are crucial performance indicators. In order to ensure that the ointment tube meets relevant standards and requirements during use, Sanquan Zhongshi's LXX-02 aluminum tube coating flexibility and adhesion tester strictly follows the testing requirements of YBB00162002-2015 "Aluminum Medicinal Ointment Tube" standard.

Aluminum tube coating flexibility and adhesion testerIt is a professional equipment used to test the coating performance of aluminum medicinal ointment tubes. It can not only test the continuity of coatings, but also accurately evaluate the flexibility and adhesion of coatings. This is crucial for ensuring the integrity of the coating of the ointment tube during manufacturing, transportation, and use.

Test steps for coating flexibility and adhesion

When conducting coating flexibility and adhesion tests, we need to follow the following steps:

1. Sample preparation: Firstly, we take an appropriate amount of aluminum medicinal ointment tube as the test sample.

2. Sample installation: Place the sample onto the rod in the schematic diagram of the coating flexibility and adhesion testing device shown in Figure 1. The tail of the tube is fitted onto the first step corresponding to the specifications of the aluminum tube, ensuring that the rod extends from the nozzle and the aluminum tube remains perpendicular to the base throughout the entire testing process.

3. Apply pressure: Next, we place the top pressure plate onto the extended rod and gently place it on top of the nozzle. Then, apply uniform pressure on the pressure plate and quickly squeeze the aluminum tube downwards. At this point, the aluminum tube should present a uniformly folded "accordion" appearance.

4. Observation result: After removing the pressed aluminum tube from the rod, we try to stretch it as close to its original length as possible. Then, cut it longitudinally and carefully observe the surface condition of the inner and outer coatings.

5. Performance evaluation: Based on the observation results, we can evaluate the flexibility and adhesion performance of the aluminum tube coating. The inner and outer coatings should be free of cracks and peeling to comply with relevant standards and requirements.

LXX-02Aluminum tube coating flexibility and adhesion testerthe advantage of

LXX-02Aluminum tube coating flexibility and adhesion testerNot only does it have high precision and reliability, but it also has the following advantages:

Easy to operate: The design of the tester is reasonable, the operation is easy to understand, and the operator can easily get started.

Widely applicable: This instrument is suitable for various specifications of aluminum medicinal ointment tubes and can meet the testing needs of different customers.

● Easy maintenance: The components of the tester are designed reasonably, easy to disassemble and clean, and convenient for daily maintenance and upkeep.

Conclusion

In summary, the LXX-02 aluminum tube coating flexibility and adhesion tester from Sanquan Zhongshi is a professional, reliable, and easy to operate device. It strictly follows the testing requirements of relevant standards and can accurately evaluate the performance of aluminum medicinal ointment tube coatings. For the pharmaceutical packaging industry, this tester is undoubtedly a tool that helps ensure the quality and safety of ointment tubes.
