Fully automatic double-sided and rolling round bottle labeling

1 Basic purpose

Suitable for single-sided and double-sided labeling of flat bottles, round bottles, and square bottles; Equipped with a rolling round bottle labeling machine mechanism, it can simultaneously attach one self-adhesive label to the circumference of the round bottle. Such as shampoo flat bottles, lubricant flat bottles, hand sanitizer round bottles, etc., with single and double side labeling, both sides are labeled together, and double labeling improves production efficiency. They are widely used in industries such as daily chemical, cosmetics, petrochemicals, and pharmaceuticals.

II Scope of Application

3、 Labeling Example

4、 Working process

Core working principle: The sensor detects the product passing through and sends a signal back to the labeling control system. At the appropriate position, the control system controls the label to be sent out and attached to the position where the product is to be labeled. The product flows through the labeling device, and the label is coated and attached to the product, completing the labeling action of one label.

Operation process:

5、 Technical parameters:(The following are the technical parameters of standard models, and other special requirements and functions can be customized).

6、 Functional Features

u Powerful functionality, one machine can achieve4Single and double-sided labeling of products (round bottles, flat bottles, square bottles, irregular bottles);

u Adopting a double-sided rigid plastic synchronous guiding chain, the bottle is automatically ensured to be neutral, with low requirements for workers to place bottles and connect them to the assembly line, greatly reducing the difficulty of workers' operations or assembly line connections. It can be produced independently or connected to the assembly line;

u Configure an elastic pressure top mechanism to ensure smooth product transportation and effectively eliminate inherent errors in bottle height;

u Configure an automatic bottle sorting mechanism that automatically separates the distance before guiding the bottles, ensuring the stability of subsequent bottle guiding, conveying, and labeling;

u Configure a dual labeling mechanism to ensure labeling accuracy for the first time, and a secondary extrusion labeling method to effectively eliminate bubbles and ensure that the label head and tail are tightly attached;

u Intelligent control, automatic photoelectric tracking, with no labeling for anything, automatic calibration for no labeling, and automatic label detection functions to avoid wasting labels and missing labels;

u The main materials of the equipment are stainless steel and wear-resistant aluminum alloy, which comply withGMPStandardized production, sturdy overall structure, and elegant appearance.
