Fully automatic single header carton labeling machine (extended version)

1、 Basic use: 1. Suitable for flat pasting of adhesive labels on unfolded large cardboard boxes. Specially designed for the labeling of large cardboard boxes, the labeling head adjustment mechanism of the gantry bracket is fixed and supported at both ends to make the labeling head more balanced. The labeling adjustment range is wide, up to a maximum width of 800mm for cardboard boxes; (Can be applied simultaneously to: folder center labeling, large PE bag labeling, large cardboard labeling, etc.); 3. The program also sets the dual label labeling function. When two identical labels are pasted on the same horizontal line on the same carton, the dual label function can be directly selected on the labeling machine. The interval between the front and rear labels can be adjusted to achieve the dual label labeling function in one go;

1Basic purpose

1. Suitable for flat pasting of adhesive labels on unfolded large cardboard boxes, specifically designed for the labeling of large cardboard boxes with a gantry bracket for adjusting the labeling head mechanism. The two ends are fixed and supported to make the labeling head more balanced. The labeling adjustment range is wide, with a maximum range up to a width of800mmCardboard box; (Can be applied simultaneously to: folder center labeling, largePEBag labeling, cardboard labeling, etc

2. Configure labeling rollers. During the cardboard box transportation process, the rollers press down on the port and then transport the labeled labels forward to prevent abnormal transportation caused by the curled edges of the cardboard box port, which may affect the labeling accuracy or get stuck;

3. The program also sets the dual label labeling function. When two identical labels are pasted on the same horizontal line on the same carton, the dual label function can be directly selected on the labeling machine. The interval between the front and rear labels can be adjusted to achieve the dual label labeling function in one go;

IIScope of Application

Applicable labels	Adhesive labels, barcodes, etc
Applicable Products	Large flat product labeling
Application Industry	Widely used in industries such as printing, stationery, electronics, pharmaceuticals, etc
Application Examples	Large cardboard boxes with barcode labels, folder seam labels, packaging box labels, board labels, etc

3、 Labeling Example

4、 Working process

Core working principle: The sensor detects the product passing through and sends a signal back to the labeling control system. The signal passes throughPLCAfter processing, the label is sent out at the appropriate time to be attached to the designated position of the product. The product flows through the labeling device, and the label is firmly covered, completing the action of attaching one label.

Operation process:

5Technical Specifications:(The following are the technical parameters of standard models, and other special requirements and functions can be customized).

Technical Specifications	Scope of Application	Technical Specifications	Scope of Application
Applicable labels	Length:6mm～250mm	Applicable product size	Long:100mm～800mm
	Width:20mm～150mm		Width:100mm～800mm
	Outer diameter（mm）：φ250 Inner diameter（mm）：φ76mm		High:5mm～20mm
Labeling speed	Stepping:10～80pcs/min	power	Traction step:570W
	Servo:15～120pcs/min		Traction servo:980W
Labeling Accuracy	±1mm
weight	about180kg	Applicable power supply	220V 50HZ
Device dimensions	(Length x Width x Height)2000mm×1000mm×1400mm

6、 Functional Features

u Wide applicability, can meet product width requirements100mm～800mmProduct flat adhesive labels;

u High labeling accuracy, driven by segmented stepper motors or servo motors for precise label delivery; The design of the label deviation correction mechanism ensures that the label does not deviate left or right during the traction process; The eccentric wheel technology is applied to the traction mechanism, and the traction label does not slip, ensuring accurate marking;

u Durable and sturdy, using a three bar adjustment mechanism, fully utilizing the stability of the triangle, the whole machine is solid and durable;

u High stability, PanasonicPLC+Weilun touch screen+Panasonic needle shaped electric eye+The wear-resistant electronic control system composed of German Sik tag electric eyes supports equipment7×24Hourly operation;

u Flexible application, capable of single machine production or assembly line production, with simple production site layout;

u Intelligent control, automatic photoelectric tracking, with no labeling for anything, automatic calibration for no labeling, and automatic label detection functions to prevent missing labels and label waste;

u Touch screen operation interface, fully Chinese annotations and comprehensive fault prompt function, with simple and quick parameter adjustment, easy operation;

u Powerful functionality, with production counting function, power saving function, production number setting prompt function, parameter setting protection function, convenient production management;

7、 Optional functions and components

① Hot code printing/Spray code function;

② Automatic material receiving function, realizing the prevention of carton stacking and automatic feeding;

③ Automatic feeding function, realizing the collection and stacking of cardboard boxes after labeling is completed;

④ Add labeling devices to achieve the function of multi label labeling;

⑤ Other functions (customized according to customer requirements).

8、 Product Details

9、 Workshop raw materials

For more detailed technical information and videos, please call us
