ZP-35D rotary tablet press
NegotiableUpdate on 01/29
- Model
- Nature of the Manufacturer
- Producers
- Product Category
- Place of Origin
Overview
ZP-35D rotary tablet press $n dual pressure, single (double) surface dispensing. Using ZP die, granular raw materials can be pressed into circular pieces, various specifications of irregular pieces, and circular pieces
Product Details
ZP-35D rotary tablet press
Equipment Introduction:
1. Double pressure, single (double) surface output. Using ZP die, granular raw materials can be pressed into circular pieces, various specifications of irregular pieces, and circular pieces
2. Equipped with overload protection device, it can automatically shut down when the pressure is overloaded.
3. The outer shell is fully enclosed and made of stainless steel material.
4. The compression chamber is surrounded by transparent organic glass and can be fully opened for easy internal cleaning and maintenance.
5. Adopting a one-stop lubrication and oil supply system.
6. This device is controlled by a touch screenPLC controlThere are two types of buttons for control, which can be customized.
Equipment parameters:
1. Quantity of stamping dies: 35 sets
2. Maximum working pressure: 80KN
3. Maximum compression diameter: 13mm (irregular 18mm)
4. Maximum tablet thickness: 6mm
5. Maximum filling depth: 15mm
6. Maximum output: 150000 ps/h
7. Rotary speed: 0-36 revolutions per minute, variable frequency speed regulation
8. Motor power: 5.5kw 380v
9. Motor speed: 1440r/min
10. Equipment weight: 1950KG
11. Dimensions: 1170 × 1150 × 1750mm
Attachment: Install 1 XCJ-36 vacuum cleaner with a power of 1.1KW.
